Danobat RT 1200

Grinding machine Danobat RT 1200, year 1980 table / table size 1400 x 700 mm
Grinding dimensions L x W x H (800) 1200 x 750 x 800 mm
Magnetic plate size L x W 1000 x 600 mm

Rapid traverse / table movement speed 1-25 m / min.
Surface maximum distance table – centre grinding wheel 1000 mm
Speeds cross 0.1-5 m / min.
Delivery / vertical movement 0.005 – 0.05 mm

Bazx8ou223
Speed / rotation spindle rpm 1500
Spindle power 7.5 kW

Grinding wheel size Ø 400 x 50 x Ø 127 mm, weight: 8,500 kg

Total power 12 kW – 380 v

Accessories: Electro magnetic plate 1000 x 600 mm coolant pendulum control
